MONORAIL carriage (MR-W-45-F-G2-V1-CN)
Item #:
MR-W-45-F-G2-V1-CN
Availablity
Out of Stock
| Material number | 580 107 468 | |
| Type (MONORAIL Carriage) | MR | |
| Carriage build form | F | |
| Buildsize | 45 | |
| Accuracy class | G2 | |
| Preload class | V1 | |
| Coating | CN |
| A | System height in mm | 60 |
| B | Carriage width in mm | 86 |
| B2 | Distance between locating faces | 20.5 |
| C1 | Position of center front lube hole | 8 |
| C3 | Position of lateral lube hole | 8 |
| C4 | Position of lateral lube hole | 31.25 |
| C7 | Position of lateral lube hole | 27 |
| J | Carriage height | 50 |
| L | Carriage length | 145 |
| L1 | Exterior fixing hole spacing | 60 |
| L6 | Steel body length | 100 |
| N | Lateral fixing hole spacing | 60 |
| O | Reference face height | 10 |
| C0 | Static load capacitiy (N) | 167,500 |
| C100 | Dynamic load capacity (N) | 93,400 |
| M0Q | Static cross moment capacity (Nm) | 4,621 |
| M0L | Static longitud. moment capacity (Nm | 2,790 |
| MQ | Dyn. cross moment capacity (Nm) | 2,577 |
| ML | Dyn. longitud. moment capacity (Nm) | 1,556 |
| Weight Rail (kg) | 2.3 |
