L2
|
Distance to bottom mounting row
|
50
|
|
*L6
|
Attachment hole start/end spacing (top)
|
55
|
|
L7
|
Attachment hole start/end spacing (down)
|
10
|
|
b2
|
Distance mounting hole bottom transverse
|
60
|
|
b3
|
Distance mounting hole front side
|
92
|
|
*b4
|
Distance mounting hole above transverse
|
50
|
|
d
|
Diameter countersink hole
|
11
|
|
d1
|
Diameter bore
|
7
|
|
d2
|
Thread
|
M4
|
|
*d3
|
Thread (top)
|
M6
|
|
h
|
Height flange
|
13
|
|
h1
|
Depth bore hole
|
6
|
|
n
|
Mounting hole above front side
|
8
|
|
n1
|
Mounting hole above front side
|
15
|
|
|
Dimension t
|
16
|
